| Length | 1833 mm |
| Width | 677 mm |
| Height | 1165 mm |
| Wheelbase | 1260 mm |
| Ground Clearance | 162 mm |
| Seat Length | 692 mm |
| Kerb Weight | Dlx – 106 kg |
| Fuel Tank Capacity | 5.3 L |
| Type | 4 stroke, SI Engine | |
| Displacement | 109.51 cc | |
| Max Engine Output | 5.88 kW @ 8000 rpm | |
| Max Net Torque | 9.05 Nm @ 5500 rpm | |
| Bore x Stroke | 47.10 mm X 63.10 mm | |
| Compression Ratio | 10.0 : 1 | |
| Fuel System | PGM-Fi | |
| Air Filter Type | Viscous Paper Filter | |
| Starting Method | Dlx. – Kick/Self | |
| Tyre Size & Type (Front) | 90/90-12 54J Tubeless | ||
| Tyre Size & Type (Rear) | 90/100-10 53J Tubeless | ||
| Brake Type & Size (Front) | Drum 130 mm | ||
| Brake Type & Size (Rear) | Drum 130 mm | ||
| Frame Type | Under Bone | ||
| Front Suspension | Telescopic | ||
| Rear Suspension | 3-Step Adjustable Unit Swing | ||
| Length | 1833 mm |
| Width | 677 mm |
| Height | 1165 mm |
| Wheelbase | 1260 mm |
| Ground Clearance | 162 mm |
| Seat Length | 692 mm |
| Kerb Weight | Dlx – 106 kg |
| Fuel Tank Capacity | 5.3 L |
| Type | 4 stroke, SI Engine | |
| Displacement | 109.51 cc | |
| Max Engine Output | 5.88 kW @ 8000 rpm | |
| Max Net Torque | 9.05 Nm @ 5500 rpm | |
| Bore x Stroke | 47.10 mm X 63.10 mm | |
| Compression Ratio | 10.0 : 1 | |
| Fuel System | PGM-Fi | |
| Air Filter Type | Viscous Paper Filter | |
| Starting Method | Dlx. – Kick/Self | |
| Tyre Size & Type (Front) | 90/90-12 54J Tubeless | ||
| Tyre Size & Type (Rear) | 90/100-10 53J Tubeless | ||
| Brake Type & Size (Front) | Drum 130 mm | ||
| Brake Type & Size (Rear) | Drum 130 mm | ||
| Frame Type | Under Bone | ||
| Front Suspension | Telescopic | ||
| Rear Suspension | 3-Step Adjustable Unit Swing | ||
