| Length | 1850 mm |
| Width | 707 mm |
| Height | 1160 mm |
| Wheelbase | 1260 mm |
|
Ground Clearance
|
162 mm |
| Kerb Weight | Dlx – 107 kg |
| Seat Length | 712 mm |
|
Fuel Tank Capacity
|
5.3 L |
| Type |
4-stroke, SI Engine
|
| Displacement | 123.92 cc |
|
Max Engine Output
|
6.20 kW @ 6500 rpm
|
| Max Net Torque |
10.5 Nm @ 5000 rpm
|
| Fuel System | PGM-FI |
| Bore x Stroke |
50.0 mm × 63.1 mm
|
|
Compression Ratio
|
10.0 : 1 |
| Starting Method | Dlx – Kick / Self |
|
Tyre Size & Type (Front)
|
90/90-12 54J |
|
Tyre Size & Type (Rear)
|
90/100-10 53J |
|
Brake Type & Size (Front)
|
Disc – 190 mm |
|
Brake Type & Size (Rear)
|
Drum – 130 mm |
| Frame Type | Under Bone |
|
Front Suspension
|
Telescopic |
|
Rear Suspension
|
3 Step Adjustable Spring Loaded Hydraulic
|
