| Length | 2015 mm |
| Width | 783 mm |
| Height | 1087 mm |
| Wheelbase | 1330 mm |
| Ground Clearance | 166 mm |
| Kerb Weight | 124 kg |
| Seat Length | 597 mm |
| Fuel Tank Capacity | 12 L |
| Type |
4 Stroke, SI Engine
|
| Displacement | 123.94 cc |
| Max Engine Output |
8.2 kW @ 7500 rpm
|
| Max Net Torque |
11.2 N-m @ 6000 rpm
|
| Fuel System | PGM-FI |
| Bore x Stroke |
50.000 × 63.121 mm
|
| Compression Ratio | 10.0 : 1 |
| Starting Method | Self start |
| Tyre Size & Type (Front) |
80/100 – 17 M/C 46P, Tubeless
|
| Tyre Size & Type (Rear) |
110/80 – 17 M/C 57P, Tubeless
|
| Brake Type & Size (Front) | Disc – 240 mm |
| Brake Type & Size (Rear) | Drum – 130 mm |
| Frame Type | Diamond Type |
| Front Suspension |
Upside down Fork (USD)
|
| Rear Suspension | Monoshock |
| Length | 2015 mm |
| Width | 783 mm |
| Height | 1087 mm |
| Wheelbase | 1330 mm |
| Ground Clearance | 166 mm |
| Kerb Weight | 124 kg |
| Seat Length | 597 mm |
| Fuel Tank Capacity | 12 L |
| Type |
4 Stroke, SI Engine
|
| Displacement | 123.94 cc |
| Max Engine Output |
8.2 kW @ 7500 rpm
|
| Max Net Torque |
11.2 N-m @ 6000 rpm
|
| Fuel System | PGM-FI |
| Bore x Stroke |
50.000 × 63.121 mm
|
| Compression Ratio | 10.0 : 1 |
| Starting Method | Self start |
| Tyre Size & Type (Front) |
80/100 – 17 M/C 46P, Tubeless
|
| Tyre Size & Type (Rear) |
110/80 – 17 M/C 57P, Tubeless
|
| Brake Type & Size (Front) | Disc – 240 mm |
| Brake Type & Size (Rear) | Drum – 130 mm |
| Frame Type | Diamond Type |
| Front Suspension |
Upside down Fork (USD)
|
| Rear Suspension | Monoshock |
