| Length | 1955 mm |
| Width | 754 mm |
| Height | 1050 mm |
| Wheelbase | 1245 mm |
| Ground Clearance | 168 mm |
| Kerb Weight | 99 kg |
| Seat Length | 676 mm |
| Seat Height | 786 mm |
| Fuel Tank Capacity | 9 L |
| Type |
4-Stroke SI Engine
|
| Displacement | 98.98 cc |
|
Max Engine Output
|
5.43 kW @ 7500 rpm
|
| Max Net Torque |
8.05 Nm @ 5000 rpm
|
| Fuel System | PGM-FI |
| Bore x Stroke |
47.0 × 57.049 mm
|
|
Compression Ratio
|
10.0 : 1 |
| Starting Method | Self / Kick |
|
Tyre Size & Type (Front)
|
2.75 – 17 41P, Tube Type
|
|
Tyre Size & Type (Rear)
|
3.00 – 17 50P, Tube Type
|
|
Brake Type & Size (Front)
|
Drum – 130 mm |
|
Brake Type & Size (Rear)
|
Drum – 110 mm |
| Frame Type | Diamond Type |
|
Front Suspension
|
Telescopic |
|
Rear Suspension
|
Twin |
| Length | 1955 mm |
| Width | 754 mm |
| Height | 1050 mm |
| Wheelbase | 1245 mm |
| Ground Clearance | 168 mm |
| Kerb Weight | 99 kg |
| Seat Length | 676 mm |
| Seat Height | 786 mm |
| Fuel Tank Capacity | 9 L |
| Type |
4-Stroke SI Engine
|
| Displacement | 98.98 cc |
|
Max Engine Output
|
5.43 kW @ 7500 rpm
|
| Max Net Torque |
8.05 Nm @ 5000 rpm
|
| Fuel System | PGM-FI |
| Bore x Stroke |
47.0 × 57.049 mm
|
|
Compression Ratio
|
10.0 : 1 |
| Starting Method | Self / Kick |
|
Tyre Size & Type (Front)
|
2.75 – 17 41P, Tube Type
|
|
Tyre Size & Type (Rear)
|
3.00 – 17 50P, Tube Type
|
|
Brake Type & Size (Front)
|
Drum – 130 mm |
|
Brake Type & Size (Rear)
|
Drum – 110 mm |
| Frame Type | Diamond Type |
|
Front Suspension
|
Telescopic |
|
Rear Suspension
|
Twin |
