| Length | 2027 mm |
| Width | 785 mm |
| Height | 1091 mm |
| Wheelbase | 1285 mm |
|
Ground Clearance
|
160 mm |
| Kerb Weight | Disc – 117 kg |
| Seat Length | 678 mm |
| Seat Height | 790 mm |
|
Fuel Tank Capacity
|
11 L |
| Type |
4 Stroke, SI Engine
|
| Displacement | 123.94 cc |
| Max Engine Output |
8 kW @ 7500 rpm
|
| Max Net Torque |
10.9 N-m @ 6000 rpm
|
| Fuel System | PGM-FI |
| Bore × Stroke | 50.0 × 63.1 mm |
| Compression Ratio | 10.0 : 1 |
| Starting Method | Self / Kick start |
|
Tyre Size & Type (Front)
|
80/100-18 M/C 47P, Tubeless
|
|
Tyre Size & Type (Rear)
|
100/80-18 M/C 53P, Tubeless
|
|
Brake Type & Size (Front)
|
Drum – 240 mm |
|
Brake Type & Size (Rear)
|
Drum – 130 mm |
| Frame Type | Diamond Type |
|
Front Suspension
|
Telescopic |
|
Rear Suspension
|
Hydraulic Type |
| Length | 2027 mm |
| Width | 785 mm |
| Height | 1091 mm |
| Wheelbase | 1285 mm |
|
Ground Clearance
|
160 mm |
| Kerb Weight | Disc – 117 kg |
| Seat Length | 678 mm |
| Seat Height | 790 mm |
|
Fuel Tank Capacity
|
11 L |
| Type |
4 Stroke, SI Engine
|
| Displacement | 123.94 cc |
| Max Engine Output |
8 kW @ 7500 rpm
|
| Max Net Torque |
10.9 N-m @ 6000 rpm
|
| Fuel System | PGM-FI |
| Bore × Stroke | 50.0 × 63.1 mm |
| Compression Ratio | 10.0 : 1 |
| Starting Method | Self / Kick start |
|
Tyre Size & Type (Front)
|
80/100-18 M/C 47P, Tubeless
|
|
Tyre Size & Type (Rear)
|
100/80-18 M/C 53P, Tubeless
|
|
Brake Type & Size (Front)
|
Drum – 240 mm |
|
Brake Type & Size (Rear)
|
Drum – 130 mm |
| Frame Type | Diamond Type |
|
Front Suspension
|
Telescopic |
|
Rear Suspension
|
Hydraulic Type |
